ICAO CodeClassificationCategory

AVAM

A1P

L

AVAMthumb image
AVAMthumb image
AVAMthumb image

Manufacturers

AVID
Avid Amphibian
AVID
Catalina
LIGHT AERO
Avid Amphibian

Technical Data

Wing Span
11
Length (m)
5.9
Height (m)
1.7
Take Off Distance (m)
80
Landing Distance (m)
90
Absolute Ceiling (x100ft)
125
Optimum Ceiling (x100ft)
80
Maximum Speed (kts/M)
70
Optimum Speed (kts/M)
60
Fuel Capacity (ltr)
70
MTOW (t)
0.6
Maximum Range (NM)
260
Persons On Board
Maximum Climb Rate (ft/min)
900

Performance

Climb
LevelSpeedRate
000-04085-90560-840
040-08085-95510-770
080-30090-95225-340
Descent
LevelSpeedRate
000-04075320
040-08085430
080-30090450
