ICAO CodeClassificationCategory

C5M

L4J

H

C5Mthumb image
C5Mthumb image
C5Mthumb image

Manufacturers

LOCKHEED
C-5M Galaxy
LOCKHEED
C-5M Super Galaxy

Technical Data

Wing Span
66.8
Length (m)
75.5
Height (m)
19.8
Take Off Distance (m)
2600
Landing Distance (m)
1100
Absolute Ceiling (x100ft)
360
Optimum Ceiling (x100ft)

Maximum Speed (kts/M)
509 / .79
Optimum Speed (kts/M)
490 / .77
Fuel Capacity (ltr)
193600
MTOW (t)
381
Maximum Range (NM)
2400
Persons On Board

Maximum Climb Rate (ft/min)
1800

Performance

Climb
LevelSpeedRate
000-100240-2701250-2000
100-200385-4201430-2000
200-300345-3601000-1430
300-400240-250670-1000
400-500240-270500-670
Descent
LevelSpeedRate
000-1002501670
100-2004202000
200-3004802000
300-4004802000
400-5004501000
