| ICAO Code | Classification | Category |
|---|---|---|
DV20 |
L1P |
L/G |
Technical Data
Wing Span (m)
10.9
Length (m)
7.1
Height (m)
2.1
MTOW (t)
0.7
Fuel Capacity (ltr)
100
Maximum Range (Nm)
520
Persons On Board
2
Take Off Distance (m)
490
Landing Distance (m)
460
Absolute Ceiling (x100ft)
140
Optimum Ceiling (x100ft)
100
Maximum Speed (kts/M)
164
Optimum Speed (kts/M)
120
Maximum Climb Rate (ft/min)
700
Manufacturers
DIAMOND DA-20 Eclipse
DIAMOND DA-20 Evolution
DIAMOND DA-20 Falcon
DIAMOND DA-20 Katana
DIAMOND DA-22 Speed Katana
DIAMOND DV-20 Katana
HOAC DV-20 Katana
