ICAO CodeClassificationCategory

GLF2

L2J

M

GLF2thumb image
GLF2thumb image
GLF2thumb image

Manufacturers

GRUMMAN
C-20J Gulfstream 2SP
GRUMMAN
G-1159 Gulfstream 2
GRUMMAN
G-1159 Gulfstream 2SP
GRUMMAN
G-1159B Gulfstream 2B
GRUMMAN
VC-11 Gulfstream 2
GRUMMAN AMERICAN
G-1159 Gulfstream 2
GRUMMAN AMERICAN
G-1159 Gulfstream 2SP
GRUMMAN AMERICAN
G-1159B Gulfstream 2B
GRUMMAN AMERICAN
G-1159TT Gulfstream 2TT
GULFSTREAM AMERICAN
G-1159 Gulfstream 2
GULFSTREAM AMERICAN
G-1159 Gulfstream 2SP
GULFSTREAM AMERICAN
G-1159B Gulfstream 2B
GULFSTREAM AMERICAN
G-1159TT Gulfstream 2TT

Technical Data

Wing Span
23.7
Length (m)
25
Height (m)
7.4
Take Off Distance (m)
1524
Landing Distance (m)
972
Absolute Ceiling (x100ft)
430
Optimum Ceiling (x100ft)
370
Maximum Speed (kts/M)
501
Optimum Speed (kts/M)
430
Fuel Capacity (ltr)
14680
MTOW (t)
29.7
Maximum Range (NM)
3250
Persons On Board
21
Maximum Climb Rate (ft/min)
2800

Performance

Climb
LevelSpeedRate
000-100300-3101670-2500
100-200340-4301670-3000
200-300420-4302000-2500
300-400545-6001250-1820
400-500525-6001000-1250
500-600525-6001000-1250
Descent
LevelSpeedRate
000-1003602000
100-2004503000
200-3004503000
300-4004202000
400-5005401000
500-6005401000
