| ICAO Code | Classification | Category |
|---|---|---|
I23 |
L1P |
L/G |
Technical Data
Wing Span (m)
8.9
Length (m)
7.1
Height (m)
2.5
MTOW (t)
1
Fuel Capacity (ltr)
170
Maximum Range (Nm)
770
Persons On Board
4
Take Off Distance (m)
600
Landing Distance (m)
600
Absolute Ceiling (x100ft)
140
Optimum Ceiling (x100ft)
100
Maximum Speed (kts/M)
153
Optimum Speed (kts/M)
143
Maximum Climb Rate (ft/min)
1000
Manufacturers
INSTYTUT LOTNICTWA I-23 Manager
PZL-SWIDNIK I-23 Manager
