| ICAO Code | Classification | Category |
|---|---|---|
IL28 |
L2J |
M/F |
Technical Data
Wing Span (m)
21.4
Length (m)
17.6
Height (m)
6.2
MTOW (t)
21.2
Fuel Capacity (ltr)
Maximum Range (Nm)
1300
Persons On Board
3
Take Off Distance (m)
1100
Landing Distance (m)
1170
Absolute Ceiling (x100ft)
410
Optimum Ceiling (x100ft)
350
Maximum Speed (kts/M)
431
Optimum Speed (kts/M)
Maximum Climb Rate (ft/min)
Manufacturers
HARBIN H-5
HARBIN HJ-5
HARBIN HZ-5
ILYUSHIN Il-28
