| ICAO Code | Classification | Category |
|---|---|---|
MGAT |
L1J |
L/G |
Technical Data
Wing Span (m)
10.1
Length (m)
12
Height (m)
4.4
MTOW (t)
8.1
Fuel Capacity (ltr)
1680
Maximum Range (Nm)
700
Persons On Board
2
Take Off Distance (m)
540
Landing Distance (m)
570
Absolute Ceiling (x100ft)
460
Optimum Ceiling (x100ft)
Maximum Speed (kts/M)
540 / .85
Optimum Speed (kts/M)
Maximum Climb Rate (ft/min)
5500
Manufacturers
MAPO MiG-AT
MIKOYAN MiG-AT
