ICAO CodeClassificationCategory

P46T

L1T

L

P46Tthumb image
P46Tthumb image
P46Tthumb image

Manufacturers

JETPROP
DLX
PIPER
PA-46-500TP Malibu Meridian

Technical Data

Wing Span
13.1
Length (m)
Height (m)
3.4
Take Off Distance (m)
724
Landing Distance (m)
595
Absolute Ceiling (x100ft)
300
Optimum Ceiling (x100ft)
240
Maximum Speed (kts/M)
262
Optimum Speed (kts/M)

Fuel Capacity (ltr)
644
MTOW (t)
2.2
Maximum Range (NM)
1070
Persons On Board
Maximum Climb Rate (ft/min)
1500

Performance

Climb
LevelSpeedRate
000-100180-2151000-2000
100-200170-180500-800
200-300170-180500-800
Descent
LevelSpeedRate
000-1001801000
100-2001801000
200-3001801000
