| ICAO Code | Classification | Category |
|---|---|---|
PA36 |
L1P |
L/G |
Technical Data
Wing Span (m)
11.8
Length (m)
8.4
Height (m)
2.3
MTOW (t)
2.1
Fuel Capacity (ltr)
320
Maximum Range (Nm)
410
Persons On Board
2
Take Off Distance (m)
530
Landing Distance (m)
360
Absolute Ceiling (x100ft)
150
Optimum Ceiling (x100ft)
130
Maximum Speed (kts/M)
120
Optimum Speed (kts/M)
104
Maximum Climb Rate (ft/min)
800
Manufacturers
AICSA PA-36 Pawnee Brave
CHINCUL PA-A-36 Pawnee Brave
JOHNSTON Super Brave
PIPER PA-36 Pawnee Brave
