| ICAO Code | Classification | Category |
|---|---|---|
PILL |
L1P |
L/G |
Technical Data
Wing Span (m)
8.8
Length (m)
8
Height (m)
2.6
MTOW (t)
1.3
Fuel Capacity (ltr)
290
Maximum Range (Nm)
680
Persons On Board
2
Take Off Distance (m)
490
Landing Distance (m)
510
Absolute Ceiling (x100ft)
190
Optimum Ceiling (x100ft)
150
Maximum Speed (kts/M)
168
Optimum Speed (kts/M)
144
Maximum Climb Rate (ft/min)
750
Manufacturers
CASA T-35 Tamiz
CASA T-35 Pillan
ENAER ECH-51 Pillan
ENAER T-35A Pillan
ENAER T-35B Pillan
ENAER T-35C Pillan
ENAER T-35D Pillan
ENAER T-35S Pillan
INDAER CHILE T-35 Pillan
PIPER PA-28R-300 Pillan
