ICAO CodeClassificationCategory

RNGR

L1P

L

RNGRthumb image
RNGRthumb image
RNGRthumb image

Manufacturers

DAC
RangeR

Technical Data

Wing Span
9.7
Length (m)
Height (m)

Take Off Distance (m)
150
Landing Distance (m)
120
Absolute Ceiling (x100ft)
140
Optimum Ceiling (x100ft)
100
Maximum Speed (kts/M)
150
Optimum Speed (kts/M)
130
Fuel Capacity (ltr)
100
MTOW (t)
0.8
Maximum Range (NM)
1200
Persons On Board
Maximum Climb Rate (ft/min)


Performance

Climb
LevelSpeedRate
000-100180-2151000-2000
100-200170-180500-800
200-300170-180500-800
Descent
LevelSpeedRate
000-1001801000
100-2001801000
200-3001801000
